Prominent Expression of Two Forms of Glutamate Decarboxylase in the Embryonic and Early Postnatal Rat Hippocampal Formation

(Downloading may take up to 30 seconds. If the slide opens in your browser, select File -> Save As to save it.)

Click on image to view larger version.

Fig. 4.
Fig. 4.

GAD67-containing neurons in coronal sections of the developing hippocampal formation at E21 and P1. A, At E21, the cell bodies of GAD67-containing neurons are less evident than at E20, but a plexus of GAD67-containing processes now occupies a substantial portion of the hippocampal and dentate marginal zones (hMZ and dMZ). B, By P1, the GAD67-containing fine fibers with periodic varicosities are extensive. The GAD67 fibers with occasional swellings occupy a large portion of the presumptive hippocampal and dentate dendritic fields, the strata radiatum and lacunosum/moleculare (R/LM) and dentate molecular layer (M). Many of these terminal-like structures lie immediately adjacent to the pyramidal (P) and granule (G) cell layers. Scale bars: A, 100 μm;B, 50 μm.

  1. The Journal of Neuroscience vol. 16 no. 21 6919-6932
