The L1-Type Cell Adhesion Molecule Neuroglian Influences the Stability of Neural Ankyrin in the Drosophila Embryo But Not Its Axonal Localization

(Downloading may take up to 30 seconds. If the slide opens in your browser, select File -> Save As to save it.)

Click on image to view larger version.

Fig. 10.
Fig. 10.

Lack of axonal neuroglian expression does not prevent the axonal localization of Dank2 protein. A–Dshow embryonic dissections of either wild type (A,C) or of the temperature-sensitivenrg3 mutation (B,D). After egg laying, before dissection all embryos were reared at nonpermissive temperature (29°C). A andB were stained for nrg180 protein using the BP-104 mAb and C and D for Dank2 protein using a mouse antiserum. Arrowheads point out stained axonal tracts in the lateral PNS. Anterior is to theleft. Scale bar, 60 μm.

  1. The Journal of Neuroscience vol. 20 no. 12 4515-4523
