The L1-Type Cell Adhesion Molecule Neuroglian Influences the Stability of Neural Ankyrin in the Drosophila Embryo But Not Its Axonal Localization

(Downloading may take up to 30 seconds. If the slide opens in your browser, select File -> Save As to save it.)

Click on image to view larger version.

Fig. 8.
Fig. 8.

In contrast to most other CNS neurons, midline neurons maintain high levels of Dank2 protein at cell contact sites in neuroglian protein-null embryos. Shown is a comparison of Dank2 immunostaining in the ventral nerve cord of stage 13Drosophila embryos. A depicts a wild-type embryo, whereas the embryo in B does not express neuroglian protein (indicated by the absence of 1B7 mAb, neuroglian-specific immunostaining). Arrowheads indicate groups of midline neuronal cells (VUMs). C depicts the distribution of the neuronal neuroglian form (nrg180) in the ventral nerve cord at embryonic stage 13. Scale bar, 40 μm.

  1. The Journal of Neuroscience vol. 20 no. 12 4515-4523
